高惯量快速制动时，需要使用外部制动电阻。TP 系列电源或TSP 系列的伺服驱动器都可链接外部制动电阻。
制动电阻有一个在 160°C 时打开的热敏开关。
| TR800-1kW | ||
| Voltage | max. 800V | |
| Continuous Power | 1kW | |
| Peak Power | 16kW / 4s (180s break) | |
| Resistance | 33Ω ±5% | |
| Isolation | 3500Vrms (1min @ 50Hz) >1GΩ @ 1000V | |
| Protection | thermal switch, opening at 160°C IP20 | |
| Mounting | vertical, i.e. the long side is vertically aligned | |
| Cooling | recommended | |
| Environment | 0 to 45°C, not condensing | |
Subject to technical changes.
